Introduction to Steel Wall Panel Installation Methods and Systems

Steel wall panels are manufactured using galvanized steel sheets and backing materials such as gypsum board, calcium silicate board, corrugated board, or honeycomb board, depending on the product configuration. With different structural designs, steel wall panels offer flexible installation options, convenient maintenance, and easy-to-clean surfaces. They are widely used in Public Buildings, including schools, commercial spaces, hospitals, and service centers.

Common Steel Wall Panel Installation Methods

Steel wall panels can be installed using different structural systems according to project requirements. Common options include the following:

1. Snap-in Structure

The snap-in system uses specially designed steel wall panel keels with three-dimensional grooves. A 5 mm black decorative joint can be reserved between adjacent panels to create a consistent joint appearance.

2. Close-Joint Structure with Flat Corner Brackets

This installation method uses a welded steel frame for leveling. The structure is reinforced with self-drilling screws to provide support and secure panel installation. The panels are installed with closely fitted joints.

3. Suspended Structure

The suspended system uses dedicated keels and matching hooks to secure the panels. Depending on the design, joints can be left between adjacent panels to achieve the required decorative effect.

4. Cladding Structure

The cladding system uses special clips to connect the facing materials. A 12 mm U-shaped decorative strip can be used to cover and finish the joints between panels.

Steel Wall Panel Keel Framework

The steel keel framework is an important component of the wall panel installation system. Its material, structural design, and connection method affect installation accuracy and overall stability.

1. Keel Material and Construction

The keel can be manufactured from high-quality cold-rolled steel sheet with a hot-dip galvanized surface. The original specifications describe a steel thickness of 0.7 mm for the keel. The keel is roll-formed as an integrated profile without welding or lamination and should meet the structural requirements of the project. Components should have suitable corrosion protection.

2. Connection and Installation

The keels are securely connected to the top and bottom tracks. Prefabricated holes and grooves on the main keels help position the components accurately. Corresponding hooks on the panels allow convenient installation. The system uses matching profiles and accessories, with prefabricated components designed to simplify on-site assembly.

3. Provision for Electrical Wiring

Horizontal and vertical keels can be prefabricated in the factory. This helps provide space for routing power, low-voltage, and communication cables during installation, according to the project layout.

Single-Keel Suspended Wall System

The metal single-sided Steel Wall Panel System consists of steel keel components and galvanized steel panel modules. The panels are connected with narrow, continuous joints and can be used to decorate solid walls. The system is designed to be removable, allowing panels to be dismantled and relocated when required.

1. Wall Thickness

The specified overall wall thickness for this system is 90 mm.

2. Panel Materials and Finishes

The solid panel modules use steel sheet facing. Available finishes described in the original specifications include 0.8 mm PVC wood-grain laminated steel sheet and pre-coated steel sheet. The surface finish is designed for good adhesion and convenient cleaning.

3. Connection Structure

The solid modules use galvanized steel keels or clip connections. The frame and panel modules are connected using a clip system, making dismantling and relocation more convenient.

4. Joint Design

The original specifications describe recessed joints between modules, with sealing strips used in the joints to help maintain the required acoustic performance. Joint dimensions and sealing details should be confirmed against the approved project drawings.

5. Concealed Fixings

Screws and galvanized steel components are concealed within the system to maintain a clean finished appearance.

Steel Components and Supporting Framework

The supporting framework is manufactured from high-quality cold-rolled steel sheet with a hot-dip galvanized surface. The original specifications state a minimum steel thickness of 1.0 mm for the relevant keel components. The keels are integrally roll-formed without welding or lamination and are designed to meet the structural requirements of the system.

The main keels are securely connected to the top and bottom tracks. Prefabricated holes, grooves, and panel hooks help achieve accurate positioning and efficient installation. The system uses factory-prepared profiles and matching accessories to simplify on-site assembly. Horizontal and vertical keels can also provide space for electrical and communication wiring.

Conclusion

Steel wall panels offer a variety of installation structures to suit different architectural and functional requirements. Snap-in, close-joint, suspended, and cladding systems provide different joint appearances and installation methods. With suitable prefabricated keels and accessories, steel wall panel systems can support efficient installation, convenient maintenance, and flexible interior design.
